Type
|
Size1
|
Block Thickness
|
Rating
|
Equivalent Wind Velocity In MPH
|
Vinyl Fixed
|
30" x 87"
|
2"
|
F-C80
|
220
|
Vinyl Fixed
|
55" x 55"
|
2"
|
F-C65
|
198
|
Vinyl Fixed
|
79" x 79"
|
2"
|
F-C35
|
145
|
Vinyl Casement
|
31" x 55"
|
2"
|
C-C40
|
155
|
Vinyl Awning
|
61" x 37"
|
2"
|
AP-C40
|
155
|
Builder Series - Vinyl
|
52" x 52"
|
2"
|
F-HC70
|
205
|
Builder Series - Vinyl
|
77" x 77"
|
2"
|
F-HC40
|
155
|
Aluminum Fixed
|
26" x 87"
|
2"
|
F-C80
|
220
|
Aluminum Fixed
|
50" x 50"
|
2"
|
F-C65
|
198
|
Aluminum Fixed
|
79" x 79"
|
2"
|
F-C35
|
145
|
Aluminum Fixed
|
31" x 87"
|
3"
|
F-C80
|
220
|
Aluminum Fixed
|
50" x 50"
|
3"
|
F-HC80
|
220
|
Aluminum Fixed
|
74" x 74"
|
3"
|
F-HC40
|
155
|
Aluminum Fixed
|
98" x 98"
|
3"
|
F-C30
|
134
|
|
|
|
Test Reports are Available Upon Request
|
All units tested in accordance with AAMA/NWWDA 101/I.S.2-97
|
1. Sizes are certified up to and including the sizes listed.
|
|
|
Type
|
Block Size
|
|
U-Value
|
SHGC
|
Vinyl Fixed
|
6"x6"x2"
|
|
0.48
|
0.54
|
Vinyl Fixed
|
8"x8"x2"
|
|
0.48
|
0.53
|
Vinyl Fixed - Solar Block
|
6"x6"x2"
|
|
0.43
|
0.26
|
Vinyl Fixed - Solar Block
|
8"x8"x2"
|
|
0.45
|
0.30
|
Vinyl Casement
|
6"x6"x2"
|
|
0.46
|
0.45
|
Vinyl Casement
|
8"x8"x2"
|
|
0.46
|
0.46
|
Vinyl Casement - Solar Block
|
6"x6"x2"
|
|
0.41
|
0.23
|
Vinyl Casement - Solar Block
|
8"x8"x2"
|
|
0.44
|
0.26
|
Vinyl Awning
|
6"x6"x2"
|
|
0.46
|
0.45
|
Vinyl Awning
|
8"x8"x2"
|
|
0.46
|
0.46
|
Vinyl Awning - Solar Block
|
6"x6"x2"
|
|
0.42
|
0.23
|
Vinyl Awning - Solar Block
|
8"x8"x2"
|
|
0.44
|
0.25
|
Builder Series Vinyl
|
6"x6"x2"
|
|
0.49
|
0.60
|
Builder Series Vinyl
|
8"x8"x2"
|
|
0.49
|
0.59
|
Builder Series - Solar Block
|
6"x6"x2"
|
|
0.43
|
0.29
|
Builder Series - Solar Block
|
8"x8"x2"
|
|
0.45
|
0.33
|
Aluminum Fixed
|
6" x 6" x 2"
|
|
0.48
|
0.65
|
Aluminum Fixed
|
6" x 6" x 3"
|
|
0.48
|
0.61
|
Aluminum Fixed - Solar Block
|
6" x 6" x 2"
|
|
0.48
|
0.32
|
Aluminum Fixed
|
8" x 8" x 2"
|
|
0.49
|
0.64
|
Aluminum Fixed
|
8" x 8" x 3"
|
|
0.48
|
0.64
|
Aluminum Fixed - Solar Block
|
8" x 8" x 2"
|
|
0.51
|
0.36
|
|
|
|
|
|
Test Reports are Available Upon Request
|
All units tested in accordance with NFRC 2001.
|
|
Type
|
Block Size
|
Status
|
|
Vinyl Fixed
|
All
|
Passed
|
|
Vinyl Casement
|
All
|
Passed
|
|
Vinyl Awning
|
All
|
Passed
|
|
Aluminum Fixed
|
All
|
Passed
|
|
|
Test Reports are Available Upon Request
|
All units tested in accordance with ANSI Z97.1-1984
|
Hy-Lite® windows qualify for use in most applications where tempered glass is required.
|
|
|
Type
|
Fed Test Std. 406
|
ASTM D14353
|
|
Vinyl Fixed
|
No Effect
|
Negligible Effect
|
|
Vinyl Casement
|
No Effect
|
Negligible Effect
|
|
Vinyl Awning
|
No Effect
|
Negligible Effect
|
|
Aluminum Fixed
|
No Effect
|
Negligible Effect
|
|
|
Test Reports are Available Upon Request
|
2. UV stability refers to discoloring of the block, or in this case the lack of discoloring.
|
3. ASTM D1435 simulates 3 years if Arizona exposure.
|
Hy-Lite windows have been engineered, tested and refined to meet performance standards in various regions across the United States. Hy-Lite windows have been tested by independent laboratories for air and water infiltration, energy efficiency, UV protection, solar heat gain, structural performance and many other significant tests. Hy-Lite windows not only meet the performance standards in different regions, they often exceed them.
For detailed test results, ratings and approvals on various
Hy-Lite products click on the PDF shown below.

Hy-Lite Test Summary
Detailed test results,
ratings and approvals on
various Hy-Lite products
PDF Size 16K
|
|
|
|
|
Test information is not intended to replace or supercede local government ordinances. Please check with your local bylaws for minimum requirements.
» Click link to download a listing by plant code of manufacturers with AAMA-certified products. AAMS Page 3
|
|
Tested to NFRC and AAMA specifications, Hy-Lite® acrylic block products offer similar structural and thermal efficiency benefits as conventional windows and they are safety glazing approved. For specific information for wind load, U-values and other testing information, view test results below.
